HK1 RBOX K8 MINI Android 14 TV BOX RK3518 Quad Core Dual Wifi Set Top Box

Specialize in OEM & ODM Customize:
● Support Boot Logo & Boot Animation Service.
● Support Pre-install APK Service.
● Support Customize UI Service.
● Support Logo Printing on the tv box.
● Support Customize Package Box and User Manual.
● Support Customize Remote Control
● Support OTA Update Service
● Support Customize Design Motherboard and House Case
● Support Open Source for SDK
● Support Free Sample servoce for OEM VIP Customer
● Support 3Years Warranty time Guarantee

GET PRICE

90 0

Description

HK1 RBOX K8 MINI tv box specifications:

System
CPU	Quad Core ARM Cortex A53
cpu	Rk3518 Quad Core ARM Cortex -A53 @2.0GHZ
GPU	Mali-450
Memory	2GB
Flash	16GB/32GB
WiFi	IEEE 802.11 a/b/g/n/ac/ax WIFI 6 2.4G/5G
Bluetooth	BT 5.0
I/O	1*HDMI	4K*2K UHD Output
	1*Reset buttom	Yes
	1*USB	USB 3.0
	1*IR Reciver	Remote Reciver Connect
	1*RJ45	NO Support
	1*TF CARD	Support 4GB/8GB/16GB/32GB/64GB/128GB/256GB
	1*DC	5V/2A
Software
OS	Android 14.0, 64 bit os
Video	Video Decoder  Real-time video decoder of MPEG-1, MPEG-2, MPEG-4 H.263, H.264/AVC, H.265/HEVC, MVC VC-1 AVS, AVS+,AVS2 H.265 HEVC/MVC Main10 L6.1  H.264/AVC BP/MP/HP profile @ level 5.1; H.264/AVC MVC; up to 4Kx2K @ 60fps  H.265/HEVC Main/Main10 profile @ level 5.1 High-tier; up to 4Kx2K @ 60fps  AVS2 4KX2K @60fps  MPEG-1, Main profile, up to 1080P @ 60fps  MPEG-2, SP@ML, MP@HL, up to 1080P @ 60fps  MPEG-4, ASP profile @ level 5, up to 1080P @ 60fps  AVS, Jizhun profile @ level 6.0; up to 1080P @ 60fps  AVS-P16 (AVS+), up to 1080P @ 60fps  H.263, up to 576P @ 60fps  VC-1, SP@ML, MP@HL, AP@L0-3, up to 1080P @ 60fpsDisplay Interface  Support HDMI 2.0b output up to 4K 10bit @60Hz  TV interface: TV encoder 10bit out for DAC  HDMI interface:  24 bit (RGB888 YCbCr444), 30 bit(RGB101010,YCbCr 420, YCbCr 444)  Max output resolution 4K for HDMI, 480i/576i for CVBS  Support 1 cluster layer, 4 smart layer  Support HDR10, HLG HDR, Vivid HDR RGB Light: adjust the lighting according to your mood.
Audio	Supports MP3, AAC, WMA, RM, FLAC
Image	HD JPEG、BMP、GIF、PNG、TIF
Language	Multi-Language
Appliactions
Online	Browse all video websites,support Netflix,Hulu,Flixster, Youtube, etc.
Apps	Apps download freely form android market、amazon app store etc.
Medium	Local Media playback,Support HDD, U Disck ,TF Card .
Talk online	Support SKYPE video call ,MSN , facebook ,twitter ,QQ etc
Others	Support Email,office suit etc. Support DLNA function Support 2.4G wireless mouse/keyboard
Packing：
Product dimension:
Single Tv box size : 777717 (MM)
Unit packing: (LxWxH): 15510848 (MM)
Unit packing (G.W.): 0.24KG
Export carton (WxHxL): 20pcs 320250230（MM）, 40pcs: 480320230（MM）
Export carton (G.W.): 5.3 KG
Qty per export carton: 20/40PCS
Accessories ：
1、HDMI cable *1
2、BT Vioce Remote *1
3、User Manual *1
4、Package box *1
5、Power Supply Cable *1
